gefran ADV200 SP Series - Page 88

88 ADV200 SP • Quick start up guide - Specification and installation
Figure 10.1.4: S8DI103 dimensions
120
70
141.2
14.6 ±0.5
6
126
(mm)
Figure 10.1.5: S8DI104 dimensions
250
89
174.6
14.6 ±0.5
16.5
177
(mm)
