ADV200 SP • Quick start up guide - Specification and installation 97
-
safety of the system.
However, if a reduction in conducted emission levels is required and the ground insulation monitoring systems
Sizes
AC Input voltage 400V-480V, System earthing IT
Heavy Duty Low Duty
EN 61800-3 :
Category / Motor cable length
Model Code Model Code
1015 FN 258 HVIT-7-29 FN 258 HVIT-7-29 C4 / 100 m
1022 FN 258 HVIT-7-29 FN 258 HVIT-7-29 C4 / 100 m
1030 FN 258 HVIT-7-29 FN 258 HVIT-7-29 C4 / 100 m
1040 FN 258 HVIT-7-29 FN 258 HVIT-16-29 C4 / 100 m
1055 FN 258 HVIT-16-29 FN 258 HVIT-16-29 C4 / 100 m
2075 FN 258 HVIT-16-29 FN 258 HVIT-16-29 C4 / 100 m
2110 FN 258 HVIT-16-29 FN 258 HVIT-30-33 C4 / 100 m
2150 FN 258 HVIT-30-33 FN 258 HVIT-30-33 C4 / 100 m
3185 FN 258 HVIT-30-33 FN 258 HVIT-42-33 C4 / 100 m
3220 FN 258 HVIT-42-33 FN 258 HVIT-55-34 C4 / 100 m
3300 FN 258 HVIT-55-34 FN 258 HVIT-75-34 C4 / 100 m
4370 FN 258 HVIT-75-34 FN 258 HVIT-75-34 C4 / 100 m
4450 FN 258 HVIT-75-34 FN 258 HVIT-100-35 C4 / 100 m
4550 FN 258 HVIT-100-35 FN 258 HVIT-130-35 C4 / 100 m
5750 FN 258 HVIT-130-35 FN 3311 HVIT-250 C4 / 100 m
5900 FN 3311 HVIT-250 FN 3311 HVIT-250 C4 / 100 m
51100 FN 3311 HVIT-250 FN 3311 HVIT-250 C4 / 100 m
61320 FN 3311 HVIT-250 FN 3311 HVIT-250 C4 / 100 m
61600 FN 3311 HVIT-400 FN 3311 HVIT-400 C4 / 100 m
Note!
Codes provided on request
Additional technical specifications are available from the manufacturer in the Schaffner website or catalogue.
Model
Dimensions Weights
(W x H x d) - mm kg
FN 258 HVIT-7-29 255 x 126 x 50 1,0
FN 258 HVIT-16-29 305 x 142 x 55 1,5
FN 258 HVIT-30-33 335 x 150 x 60 1,8
FN 258 HVIT-42-33 329 x 185 x 70 2,5
FN 258 HVIT-55-34 329 x 185 x 80 3,0
FN 258 HVIT-75-34 329 x 220 x 80 4,3
FN 258 HVIT-100-35 379 x 90 x 220 5,6
FN 258 HVIT-130-35 439 x 110 x 240 7,1
FN 3311 HVIT-250 170 x 140 x 267 2,7
FN 3311 HVIT-400 175 x 140 x 280 3.3
.
