ADV200 SP • Quick start up guide - Specification and installation 89
Figure 10.1.6: S8DI105 dimensions
250
89
174.6
14.6 ±0.5
16.5
177
(mm)
Figure 10.1.7: S8DI106, S8DI107 and S8DI108 dimensions
250
89
16.5
186
26 ±0.1
177
(mm)
