ADV200 SP • Quick start up guide - Specification and installation 57
• PAR 750 Ramp In 0 = Pad 5
• PAR 752 Ramp Out 0 = Pad 5
This setting will automatically reset the system in case of Undervoltage.
5. Select PAR 11008 Control Mod
Proceed to Step 9.
Step
9 – Abilitazione applicazione Solar Pump
Menu 27 SOLAR PUMP / CONFIGURATION
Enable = On (CONFIGURATION Menu).
• PAR 11002 Max Pump Speed = set the value desired
• PAR 11004 Min Pump Speed = set the value desired
Digital Start)
manual).
a) Programming the dedicated input for the radiation sensor. If the sensor is used with an analog input,
check the type of sensor used (if it is for current or voltage) and set the parameters in the Analog Input
System Menu.
c) Set the input source on the Multi Source control.
-
tion with a DC source and switching to AC or for shut down (for more information see the ADV200 SP FP
manual).
-
ADV200 SP FP manual).
Note! The MPPT algorithm must be coordinated with the DC-BUS voltage control. In general, the DC-LINK reference voltage
should be well tracked with respect to the voltage calculated by the MPPT algorithm. The user can check this condi-
tion with the parameters PAR 12012 (ref) and 12047 (real) in the Monitor Menu.
-
Note! Restart times that are too fast may cause the inverter to wear prematurely due to its continuous switching on and off.
9. Set the additional functions required in the Process menu (dedicated functions for pump control).
Proceed to Step 10.
