Rev. 00 04/19
OptiCenter OC06 Maintenance / Repairs
85
21.
22. The OptiSpeeder is cleaned, the powder from the OptiSpeeder is
transported to the booth
23. The powder from the booth is fed into the powder bag
24. The process step is complete once this symbol is displayed
(after approx. 180 seconds for intensive cleaning and approx. 30
seconds for quick cleaning).
25.
– The powder hoses are cleaned and the powder is transported to
the booth
– The powder from the booth is fed via the cyclone into the powder
bag
– The corresponding cleaning program is displayed on the
OptiStar control units:
26. The process is complete once this symbol is displayed.
