Rev. 00 12/22
18 • Product description OptiMove CR09-C
Schematic presentation
Fig. 4: Schematic presentation
1 Axis control
2 Frequency converter
3 Pulse generator wiring
4 Pulse generator
5 Motor cables
6 Drive motor
7 Signal line
8 Axis adapter
