Rev. 00 12/22
44 • Operation OptiMove CR09-C
2. Push the button
– It is switched between the levels.
3. Push the button
– The device is switched off
By switching off the equipment (also when the equipment is
disconnected from the mains), the actual settings are retained.
Travel to reference point
In order that the axis control unit can enter the position of the axis as
accurately as possible during operation, the triggered axis must first travel
to the reference point each time it is switching on. The prerequisite for this
is that the reference point is already set correctly (see also the
corresponding instructions in the respective axis operating manual).
The axis must also be referenced again after each axis-specific
error (H01, H02, H03, H04).
– If the axis is referenced, it cannot be referenced a second time
unless the above conditions are given.
1. Push the button
– The OptiMove control unit is switched on.
– The blinking triangle above the key indicates that reference
point travel has not been carried out yet.
2. Push the button
– The control unit starts the reference travel
3. At the end of the reference travel, the triangle above the key
expires and the axis is referenced
If the axis can collide somewhere, or the guns are incorrectly
mounted, or the lower reversing point is situated too low, the axis
can be stopped by pressing the key. By pressing the key
again, the reference travel will continue.
The procedure described above relates to the reference point traveling in
manual operation.
Start/stop the axis
1. Switch on the axis control unit (see also "Switch on/off the axis
control unit")
2. If necessary, change to another program (see also "Program
change")
3. Press the key.
– The axis is started, and the selected program is activated.
