Page 171
DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
58 3 WASHER LOCK M6-1/4
59 1 INTAKE ADAPTER
60 1 GASKET, AIRBOX TO CARB/MIXER
61 1 GASKET, MANIFOLD TO CARB/MIXER
62 4 BOLT, CARB MOUNT M6 – 1.0 X 85
63 1 NUT HEX LOCK M3 – 0.5
64 1 ASSY, CONTROLLER
65 1 BALL STUD, 10 MM
66 1 ASSY, THROTTLE ROD
67 1 GUARD, FAN
68 2 GASKET INTAKE
69 1 BREATHER HOSE
70 4 SCREW SHC M8 – 1.25 X 20 G12.9
71 2 WASHER LOCK M8 – 5/16
72 2 SCREW HHC M8 – 1.25 X 85
73 1 STARTER MOTOR
74 6 SCREW HHFC M8 – 1.25 X 14
75 2 LIFTING HOOK
76 1 WRAPPER OUTER CYLINDER 1 CLEAR
ZINC
77 1 WRAPPER INNER CYLINDER 1 CLEAR
ZINC
78 1 TUBE, DIPSTICK GTH 530
79 1 ASSY, DIPSTICK /TEXT ORG
80 1 BLOWER HOUSING
81 6 SCREW HHFC M6-1.0 X 10 G8.8
82 3 SCREW HHFC M6-1.0 X 8 G8.8
83 1 WRAPPER INNER CYLINDER 2 CLEAR
ZINC
84 1 WRAPPER OUTER CYLINDER 2 CLEAR
ZINC
85 1 GASKET, OIL FILTER ADAPTER
86 1 ASSY, DIRECT OIL COOLER ADAPTER
87 2 SCREW PLASTITE HI-LOW #10X3/8
88 3 SCREW HHC M6 – 1.0 X 25
ITEM QTY. DESCRIPTION
89 1 OIL FILTER
90 1 THERMAL SWITCH
91 2 SCREW PPHM M3-0.5 X 6 SEMS
92 1 ASSY OIL DRAIN HOSE ORG
93 1 OIL PRESSURE SWITCH HOBBS 5PSI
94 1 KEY, WOODRUFF 4 X 19D
95 1 ASSY, GROUNDING WIRE
96 1 ASSY IGNITION COIL CYLINDER 1
1 ASSY IGNITION COIL CYLINDER 2
97
98 1 ASSY, MIXER DUAL FUEL
99 4 CLAMP, HOSE OETIKER STEPLESS
18.5mm
100 1 HOSE 3/8”ID X 6” SAE J30R9
101 1 HOSE 3/8”ID X 7.25 SAE J30R9
102 1 BACKING PLATE, GT-530 ZINC
103 1 ASSY, FLYWHEEL & RING GEAR
104 1 FAN, FLYWHEEL, 20 FIN, 218.8 OD
106 2 SCREW HHFCS M8 – 1.25 X 12 C8.8
107 1 NUT HEX M20 – 1.5
108 1 WASHER BELV – 20 X 2.2
109 1 PLATE, FAN
110 1 ASSY, GROUND WIRE CONNECTOR
111 1 OIL COOLER
112 13 SCREW HHFC M6 – 1.0 X 14
113 1 CENTER BAFFLE
114 1 INTAKE MANIFOLD
115 1 FRONT COVER
116 1 ELBOW - 1/8” NPT
117 2 SCREW, HHFC M6-1.0 x 12
118 4 SCREW, HHFCS M6-1 x 12 CLEAR ZINC
119 4 SCREW, HHC M6-1 x 25 SEMS
120 1 CLAMP HOSE .38-.87
121 1.5 HOSE 1/4 ID LPG 350PSI UL21
