Note:
1. To upload snapshots, make sure to enable Snapshot in Video & Audio. For more
detailed instructions, refer to 4.3.3 Snapshot.
2. If Overwrite Storage is not selected and the storage is full, snapshots can no longer be
taken.
Intelligent
This function is used to store snapshots taken for smart functions such as face detection.
Figure 4-67
1. Type the Server IP address.
2. Change the Port No. of the FTP server if needed.
3. Type the Username and Password of the upload account.
4. Under Save To Root Directory, select a directory in which to save the images, or select
Custom to name a storage folder on the FTP server.
5. Under File Name, select a Separator and a combination of Naming Element(s) to name
the snapshots captured. A template of the file name is shown.
