1.7.1.3 GV-VS11
1
1
2
3
5
4
Figure 1-5
No. Name Function
1 Video Input 1 plug for video input.
2 Default Button
It resets all configurations to their factory settings. See 6.4
Restoring to Factory Default Settings.
3 Audio Input 1 plug for audio input.
4 Ready LED
This LED is on, indicating the GV-Video Server is ready for
connection.
5 Power LED This LED is on, indicating the power is supplied.
1.7.1.4 GV-VS12
Figure 1-6
No. Name Function
1
USB Port 1 USB port for installing the portable storage device.
2
Speaker Output A plug for the speaker device.
3
Audio Input 2 plugs for audio inputs.
4
Video Input 2 plugs for video inputs.
8
