Getac S400 User Manual

Getting Started 1-15
Ref
Component
Description
See Also
Both indicators blink green at the same time when
the optional hard disk drive heater is on.
P. 8-9
If you turn on the system when the temperature
is too high for operation, both indicators blink
green for 10 seconds to indicate the system will
remain off as a protection. Wait till the
temperature drops down.
P. 8-9
Hard Disk/
DVD Drive
Blinks green when computer is reading / writing
data to the hard disk or DVD drive.
Num Lock
Lights green when Num Lock is on.
P. 2-3
Caps Lock
Lights green when Caps Lock is on.
P. 2-3
WLAN
Lights green when WLAN radio is on.
P. 2-20
Bluetooth
Lights green when Bluetooth radio is on.
P. 2-23
WWAN
Lights green when WWAN radio is on.
P. 2-29

Fingerprint
Scanner
Serves as the fingerprint verification, preventing
unauthorized access to your computer.
P. 2-30

Getac S400 Specifications

Power

ac adapter power	90W
ac adapter voltage	100-240V
ac adapter frequency	50/60Hz

Battery

battery capacity	8700mAh
battery type	9 cells Li-Ion

Temperature

operating temperature range	0°C to 60°C
storage temperature range	-40°C to 71°C
humidity	95% RH, non-condensing

System Memory

default memory	4GB DDR3
maximum memory	8GB
memory type	DDR3

Display

display size	14 inches
display resolution	1366 x 768
optional display brightness	800 NITs

Ports & Interfaces

usb 3.0 ports	3
usb 2.0/eSATA combo port	1
serial port	RS-232 x 1

Weight and Dimensions

dimensions	348 x 258 x 49.2 mm
weight	2.9 kg
