Instruction Manual ProfiLux 4 / 4e
EN 2019-01-22 32
The lower lines display current values, e.g. brightness of an illumination channel or lunar
phase, state of stream pumps or temperature.
The viewable data can be freely adjusted as needed. The basic setting does not display all the
values described below. However, you can adjust the display settings accordingly.
Displays the current brightness of a lighting channel in
percent.
Displays the current power of two current pumps in
percent.
Display the current moon phase in percent (0% = New
moon, 100% = Full moon).
Display of the current sensor values (-):
When the minus symbol is displayed, the control has
activated the corresponding switching socket (if present)
to reduce the pH value.
Display of the current sensor values(+):
When the plus symbol is displayed, the corresponding
switching socket (if present) has activated the control to
increase the pH value.
When the cooling symbol (*) is displayed, the control has
activated the corresponding switching socket (if present)
to lower the temperature.
When the substrate heater and tubular heater symbols are
displayed, the control has activated the corresponding
switch sockets (if present) to increase the temperature.
* Above illustrations are exemplary.
6.1.3 Standard Display
During normal operation, the following information is displayed on the display:
