Instruction Manual ProfiLux 4 / 4e
EN 2019-01-22 7
For your own safety, please look at the hazard prevention and safety instructions in the
chapters that follow.
2 General
2.1 About this Manual
These instructions apply to the Controller ProfiLux 4 / 4e.
2.2 Features
• Illuminated blue graphical display
• Control panel with capacitive buttons
• LED Status indicator
• 2x Connections for Powerbar (Red Western socket), ProfiLux 4 only
• 1x Digital light control interface for Mitras Lightbar and compatible devices (Black
Western socket, on the right next to power supply inputs) or RS232
• 3x Expansion slots (2x external, 1x internally accessible)
• 2x PAB Ports (Black Western sockets)
• 2x Level sensor ports (Double allocation)
• 3x 1-10V-interfaces (Yellow Western sockets, double allocation)
• 1x Power failure monitor port
• 1x USB Connection
• 1x GHL Control Pad Connection
• 1x DCF Receiver Connection
• 1x AUX Connection
• 1x Connection for power supply unit (12V DC hollow socket)
• 4x Sensor Connections for Temperature, pH/Redox, Redox/pH, Conductivity (White BNC-
connectors) (ProfiLux 4)
• If the device has become wet or dirty, thoroughly clean and dry it
with a dry cloth.
DANGER
• The device may not be operated if it has been damaged in any way
(e.g. damaged power cord or plug, liquids or objects have gotten
into the interior, device has been exposed to excessive moisture,
the normal operation is disturbed, or the device has been dropped.)
