Instruction Manual ProfiLux 4 / 4e
EN 2019-01-22 49
pH measurement
BNC input for pH sensor, accuracy 0.1 pH, pH range 3.0 to
10.5 pH
Temperature
measurement
BNC input for the supplied digital temperature sensor,
accuracy 0.1°C (33.8°F), Measuring range 0.0°C to 40°C
(32°F – 104°F)
Conductivity measurement
BNC-input for Conductivity sensor, , in fresh water accuracy
1 µS, measurement range 0 µs to 2000 µS, in salt water
accuracy 0.1 mS, 0 mS to 100 mS (ProfiLux 4 only)
Redox measurement
BNC input for Redox sensor, accuracy 1 mV, measurement
range -1000 mV to 1000 mV
Oxygen measurement
BNC input for oxygen sensor, accuracy 0.1%, measurement
range 0% to 150%; optional
Humidity-Temp
measurement
RJ12 socket to connect a combined sensor, accuracy 0.1%,
measurement range 1% to 99%, optional
Mitras Lightbar/Slimline
port or RS232
RJ45 socket
PC connection
USB Port
L ports
3 RJ12 sockets with 2x 1-10 V interfaces each and 2 relay
signals
Powerbar control
2 RJ12 sockets with 4 channels each (ProfiLux 4 only)
PAB ports
2
Dimensions
220 mm (8.66”) x 150 mm (5.9”) x 55 mm (2.17”)
GHL Advanced Technology©
GmbH & Co. KG
Marie-Curie-Straße 20
67661 Kaiserslautern
www.aquariumcomputer.com
