MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017 Page 5-7

Troubleshooting Service

9 Select IDE Channel 0 Master and press Enter. The Integrated Drive Electronics (IDE)

Channel 0 Master screen appears.

Figure 5-5: IDE Channel 0 Master Screen

Step 10

Step 11

10 Set the “Access Mode” field to LBA.

11 Select IDE HDD Auto-Detection and press Enter.

12 Press Esc to return to the Standard CMOS Features screen.

13 If the server has a floppy drive, verify if the value for “Drive A” is 1.44M, 3.5 In. or, select

None.

Figure 5-6: Verifying Value for Drive A
