MDE-5369E FlexPay™ IV (with Omnia) Programming and Service Manual · April 2020 Page 6-11
Resetting the Network Configuration to Factory Values Troubleshooting
After completing the procedure, you can access the configuration web application using the
default IP parameters and apply any changes to the Omnia configuration.
7 Reconfigure the PC network configuration as follows:
• IP: 17
2.16.100.15
• Netmas
k: 255.255.255.0
8 Connect a PC with a browser to service port.
9 Open a browser and type http://172.20.100.254:3000/ in the address field.
10 Apply changes to the Omnia configuration as needed. Configure the Omnia network as
follows:
External Omnia IP address for Side A
Address: 10.5.55.71
Netmask: 255.255.255.0
External Omnia IP address for Side B
Address: 10.5.55.72
Netmask: 255.255.255.0
Internal Omnia IP address
Address: 172.20.100.254
Netmask: 255.255.255.0
Note: Netmask should be 255.255.255.0
Note: If the process was successful, a log file of the change will
be automatically copied to the
usbconfig.
The network configuration should be as shown in Figure 6-9.
Figure 6-9: Network Configuration
Note: The log file of the operation is located in the folder “usbconfig”.
11 Restore your PC network configuration.
