Configuring Omnia PCB Omnia Home Page
Page 5-8 MDE-5369G FlexPay™ IV (with Omnia V04.07) Programming and Service Manual · March 2021
The Omnia home page includes the following:
A status images group with Networks status, CloudApp status, MultimediaApp, and Pump
Status is displayed.
Notes: 1) OpenApps status data is shown only if related applications are configured/activated.
2) Pump status is shown only for Door Sensor, where the pump is connected via RTP
protocol.
The page also includes a Meters button to display self-updating meters with CPU Average
Load, CPU Temperature, and Memory Load.
Section Tabs / Button
Setup Wizard button Used for adding new configuration or importing existing configuration.
Firmware Version Includes the following options:
• Factory Software Version
• Core-FWR[Build]
• Linux Kernel release
Applications Version Includes the following options:
• CloudApp version
• ActivityMonitor version
• Pumpproxy version
• Crindproxy
• Mediasyncclient
• Mediamanager
Applause Includes the following options:
• Configured
• Operative
OpenApps Version Includes the following options:
• List of installed Apps
• List of OpenApps contents
• List of OpenApps layout
Board Information Includes the following options:
• Board Version
• Board Part Number
• MAC Address
• PPN
• Current Time
•Up Time
