Parts List
GBF-70 Fryer
ITEM PART NO. QTY DESCRIPTION
1
21447 2 ELEMENT, 208 V, 9975 W, FIREBAR
21448 2 ELEMENT, 240 V, 9975 W, FIREBAR
21449 2 ELEMENT, 480 V, 9975 W, FIREBAR
2 21596 1 THERMOCOUPLE‐ J, DUAL, 7‐1/2”, UNGROUNDED (HI‐LIMIT PROBE)
3 20439 1 THERMOCOUPLE, J‐TYPE, 3”, UNGROUNDED (ADD LEVEL PROBE)
4 23900 1 THERMOCOUPLE, J‐TYPE, 3”, GROUNDED (VAR. OIL TEMP PROBE)
5 20362 1 THERMOCOUPLE, J‐TYPE, 7‐1/2”, UNGROUNDED (ELEMENT TEMP PROBE)
6 45400 4 CONNECTOR, 0.190 ID, 1/4 NPT, SWAGELOCK
7 98148 1 ELEMENT BRACKET, HI‐LIMIT, GAPPED
8 94462 2 STRAP, ELEMENT BRACKET
9 94834 1 ELEMENT BRACKET, FLUSH , ELEM. TEMP
10 97509 1 ELEMENT SUPPORT BAR
11 98265 1 PLATE, DRAIN TUBE SPRING HOOK
12 41432 1 VALVE, 1‐1/2 NPT X 1‐1/2 TUBE, FULL PORT
13 33634 1 NIPPLE, 1/2 NPT X 15‐1/2”, BLACK PIPE
14 42252 1 ELBOW, 90‐DEG, 1/2NPT, S/S
15 40889 3 ADAPTOR, 1/2‐COMPRESS TO 1/2‐NPT
NOTE:
To avoid potential leaking, when replacing Thermocouples it is necessary to also replace the ferrule inside the Swagelock
connector ...
Order part no. 45111.
7.09 Fry Vat Assembly (per Vat)
