GBF-70 Fryer
Installation
2.04 Electrical Specifications: Single & Banked (per Fryer Unit)
Voltage Ph Hz
Watts
Amps
Breaker Size
Unit powering pump Unit without pump
208
3 60 19,950
57 55 70
240 50 48 60
480 26 24 35
2.05 Electrical Connection
NOTE:
All electrical materials (breakers, conduit, wire, hardware, etc.) and labor necessary for electrical installation
shall be supplied by the customer. All work should be performed by a qualified professional electrical contractor
and comply with all code requirements.
Giles shall not be responsible for code compliance in regard to installation and use of this appliance.
1. As needed, install appropriate circuit breaker(s) in the main electrical panel. See Section 2.04.
2. It is recommended that a disconnect switch box be installed between main panel and appliance as a service
disconnect.
3. See Figure 2.05.1. Connect 1‐1/4” flexible conduit from electrical panel (or disconnect switch) to the fryer.
Route conduit through rear panel to the back side of the fryer service box and attach with appropriate conduit
fittings and connectors. Allow enough length so that unit can be moved easily for cleaning or service.
4. See Figure 2.05.1. Open the cabinet and remove service box cover.
5. Connect ground wire between ground lug and proper earth ground.
6. Route appropriately sized power wire from the main panel (or disconnect switch if installed) through to the
front service box.
7. See Figure 2.05.1. Connect the supply power wires to distribution block inside service box and reinstall cover.
8. Banked fryer system installations, require that each fryer in the battery be connected as explained above.
