Installation
GBF-70 Fryer
5. If the unit is equipped with the optional on‐board Oil Top‐Off
system (not bulk fresh oil), press and momentarily hold the
OIL FILL PUSHBUTTON ④ on the control panel. You
should hear the top‐off pump start to run. Release the
button and the pump should stop.
If either pump does not run or suction is not detected
at the filter pan coupling ②, refer to Section 6.02,
Troubleshooting Procedures, else proceed to next
section.
2.09.3 Filter Pump Test
1. Open cabinet door (unit with filter pan on banked system). If
needed, disconnect and remove the filter pan from the unit.
2. Place the Oil Return valve ① in the [FILL POT] position
(horizontal).
3. Firmly press the palm of the hand over the Filter Pan Coupling
② on the front brace.
4. While covering the opening with the hand, place the Pump Switch
③ in the [PUMP] position. The filter pump will start ... if suction
is felt, it is operating correctly. Return switch to [OFF]. Allow
pump to ONLY run long enough to check for suction.
The following test confirms that the filter system pump is operating properly.
2
1
3
IMPORTANT!
Before using the appliance for the first time, it is necessary to perform a Boil‐Out Procedure (for all units of a banked
system). This process will remove residue which may remain from manufacturing processes, or dirt and debris that may
have accumulated during warehousing and shipment. For details concerning the Boil‐Out Procedure see Section 5.01.
2.09.4 Initial Boil-Out Procedure
OIL TOP‐OFF PUMP (if equipped):
