17
Model: GBF-70
Overview
3.01 Control Panel
Item Description Function
1 Power Switch
Turns appliance power ON/OFF. Pressing top of switch turns power ON,
pressing bottom turns power OFF.
2 Heat Switch
Place switch in [HEAT] position to enable heating elements. If actual oil
temperature is lower than the controller setpoint, elements will be turned
ON and cooking oil will begin heating. When in the [OFF] position, elements
are disabled and will not turn ON.
3 Computer Controller
Regulates cooking oil temperature and controls cooking time. Features fifty
(50) programmable menu item cooking presets, Boil‐Out program, Force
Filter function, Auto‐Cool Mode, password control & multi‐language
selection. Monitors fryer operation, displays error/alarm message and
operational instructions.
4 Power Indicator Light
Green light illuminates when the appliance Power Switch is in the [ON]
position.
5 Heat Indicator Light
Amber light illuminates to indicate that heating elements are energized and
heating the oil. The light cycles ON/OFF while cooking, as oil temperature is
regulated by the controller.
6 Hi‐Limit Indicator Light
The red High‐Limit light illuminates to indicate uncontrolled overheating
and that the high‐limit safety thermostat has shutdown heating elements.
Should this light come on during operation, refer to the Section 6,
Troubleshooting in this Manual. DO NOT ATTEMPT TO COOK IN A FRYER
WHEN THE HIGH‐LIMIT LIGHT IS ON!
7
Fill/Top Off Control
Switch
(Optional)
Depending on optional fryer configuration, switch activates either the on‐
board top‐off pump, or the pump in a customer‐provided bulk oil
management system, to deliver with fresh oil to a cook vat. The switch
position is plugged if not used.
8
Lift Switch
(Optional)
Enables/disables automatic Basket Lifts. Lifts are active when in the [LIFT]
position, they WILL NOT operate if switch is in the [OFF] position. This
switch is not installed unless fryer is equipped with optional basket lifts; the
position is plugged if not used
9 Pump Switch
Turns Filter Pump ON/OFF for filtering cooking oil or removing waste oil
from fryer. On banked systems, this switch is present only on the unit
containing the filter pan; the position is plugged if not used.
