19
Model: GBF-70
Overview
Item Description Function
1 Oil Return Valve
Directs oil flow to the particular vat from either the fryer filter system, a bulk
oil management system, or the Oil Top‐off system. THESE VALVES SHOULD
REMAIN CLOSED UNLESS IN USE.
2
Waste Oil Discharge Hose
Coupling
Connects the Waste Oil Discharge Hose to the filter system for pumping
waste oil into a portable oil caddy. On banked systems, the coupling is only
present on the unit with filter pan.
3 Drain Valve Handle
Operates the vat Drain Valve. Always ensure the valve is [CLOSED] before
adding cooking oil or preparing for boil out. NOTE: Fryer will NOT heat
unless Drain Valve is completely closed. Fryer will enter error/alarm state
and elements shutdown if opened while cooking is in progress.
4
Filter Pan
Coupling
Connects the filter pan hose to the Oil Filtration System.
5
Waste Oil Valve
(OPTIONAL)
If fryer is connected to a third‐party bulk waste oil collection system, opening
this valve directs pump discharge to the waste oil collection system. This
valve is not present unless the Bulk Waste Oil option is installed.
6 Oil Wand Valve
Opening valve allows waste oil to be discharged through the Waste Oil
Discharge Hose supplied with the fryer. Hose must be connected at coupling
or pump will stall, which could damage pump seals.
7 Fryer Filter Pan
Collects used cooking oil drained from the fryer vat and contains oil filtering
media. See Section 3.03 for additional detail.
8 Filter Pan Cover
Prevents splash and splatter as oil is being drained into the Filter Pan.
Helps keep floor and cabinet interior cleaner. Also, helps to avoid possible
contamination of oil while temporarily contained in filter pan.
9 J‐I‐B Suction Tube
Optional Jug‐In‐Box (J‐I‐B) Top‐Off feature ... provides hands‐free capability
to easily maintain proper oil level. Suction tube is inserted directly into a
packaged jug of fresh oil. As needed, oil is drawn from jug and pumped to
the selected fryer vat. Available only for banked fryer system, oil Saddle
Tank used for single fryer, see Section 3.04.
10 J‐I‐B Shelf Holds a standard size 33‐lb Jug‐In‐Box of fresh cooking oil.
11 Fresh Cooking Oil Jug Purchased container of fresh cooking oil (customer supply)
3.02 Lower Cabinet
