Model: GBF-70
Overview
Item Description Function
1 Filter Pan Cover
Helps contain oil splash and spatter as oil is being drained into the filter pan
from the vat(s) ... helps minimize clean‐up required for floor and/or cabinet
interior.
2 Crumb Screen
Filter pan insert designed to capture large breading crumbs and cooking
residue as oil is drained from vat.
3 Hold‐Down Frame
Secures filter media tightly against pan bottom to provide a good suction
seal. Improper placement can result in poor filter pump performance.
4 Hold‐Down Levers [4}
Locks hold‐down frame in place. Failure to have these Levers properly
engaged will potentially cause poor filter pump performance.
5 Filter Paper
Standard, disposable. paper filter media. Filters fine sediment and residue
from cooking oil during the filtering cycle.
6 Filter Pan Screen Supports filter media above the Filter Pan bottom..
7 Filter Pan
Collects used cooking oil for filtering; contains filter media which filters and
reconditions oil during the filter cycle. Features casters and is removable
for cleaning and changing of filter media.
8 Filter Pan Plumbing
Connects Filter Pan to the oil filtration system via quick‐connect/disconnect
coupling. Must be disconnected before pan can be removed.
3.03 Filter Pan Assembly
