Parts List
GBF-70 Fryer
1 21379 1 CONTROLLER, CC10, DUAL TIMER
2 21190 1 SWITCH, ROCKER, ON‐OFF, 250V, 20A, DPST
3 21052 3 / 2 / 1 SWITCH, ROCKER ,ON‐OFF‐ON, 250V, 20A, DPDT
4 20398 1 INDICATOR LIGHT, GREEN, 250VAC
5 20399 1 INDICATOR LIGHT, ORANGE, 250VAC
6 20402 1 INDICATOR LIGHT, RED, 250VAC
7 66126 1 LABEL, CONTROL PANEL, CC10, GBF
8* 20307 3 RETAINING CLIP, INDICATOR LIGHT
9 20621 1 / 2 PLUG, SWITCH CUT‐OUT (for units WITHOUT #3 installed)
10 41454 1 / 2 GASKET, SWITCH HOLE PLUG (for units WITHOUT #3 installed)
11 21555 1 / ‐ SWITCH, PUSH‐BUTTON, MOMENTARY, 10A
12 21556 1 / ‐ PLUG, PUSH‐BUTTON SWITCH
ITEM PART NO. QTY DESCRIPTION
NOTE:
• PUMP switch (item #3) not installed in panel of add‐on units of banked system ... replaced with (1) Item #9 + (1) Item #10
when not installed.
• LIFT switch (item #3) not installed in panel if unit is not equipped with optional basket lifts ... replaced with (1) Item #9 +
(1) Item #10 when not installed.
• Push‐Button switch (item #11) installed only when unit is equipped with Vat Top‐Off and/or Bulk Fresh Oil Option ... if not
installed, replaced with Plug (item #12). Switch is only installed on (1) unit of a banked system, as needed.
7.02 Control Panel - Single Unit & Banked System Main Unit
* Not Shown
