75
Parts List
GBF-70 Fryer
1 21592 1 LIMIT CONTROL, SAFETY, 450‐DEG F, DUAL
2 21203 1 RELAY, SPST‐NO‐NC, 240VAC
3 37585 2 DIN RAIL, TERMINAL BLOCK MOUNT, 3.0”
4 21438 1 SOCKET, RELAY, DIN, 250V, 10A
5 21437 1 RELAY, DPDT, 240VAC COIL, 8A
6 21504 1 DIST.BLOCK, 6‐PL, 12‐26 AWG, RED
7 21510 1 DIST.BLOCK, 12‐PL, 12‐26 AWG, BLACK
8 21496 2 END BRACKET CLIP, DIN RAIL, PTFIX, NS‐35
9 22976 1 AUDIOLARM, CONTINUOUS, 2‐12 VDC
10 21950 2 HOLDER, FUSE, 300V, 15A, SC 0 TO 15
11 21900 2 FUSE, 15‐AMP, SC‐15
12 20366 1 TRANSFORMER, 20VA, 115/230V, 60HZ, CL2
ITEM PART NO. QTY DESCRIPTION
7.03 Front Header Component Box (behind Control Panel of each unit)
