83
Parts List
GBF-70 Fryer
1 97177 1 MANIFOLD. OIL RETURN, BANKED UNIT (2 OR 3)
2 41504 2 SNUBBER, 1/4NPT X 1/4NPT, 45‐MICRON
3 40906 1 PIPE PLUG, 1/4‐18 NPT, S/S, HEX SOCKET (MANUAL UNITS ONLY)
4 21440 1 TRANSDUCER, PRESSURE, 0‐50 PSI ... CABLE = P/N 21357 (AUTOMATED UNITS ONLY)
5 21434 1 PRESSURE SWITCH, 35 PSI, 10A
6 40889 VAR. ADAPTOR, 1/2‐COMPRESS TO 1/2‐NPT
7 41081 4 HOSE, CORRUGATED, SS, 1/2 NPT X 30”
8 40907 1 HOSE, CORRUGATED, SS, 1/2 NPT X 18”
9 41119 2 HOSE, CORRUGATED, SS, 1/2 NPT X 24”
OPTIONAL BULK OIL SYSTEM CONNECTIONS ONLY: WASTE OIL TANK
10 41081 2 HOSE, CORRUGATED, SS, 1/2 NPT X 30”
11 46475 1 ADAPTER, QUICK SEAL, 1/2
12 41410 1 PLUG, PIPE, THREADED, 1/2 NPT (Removed when connected to system)
OPTIONAL BULK OIL SYSTEM CONNECTIONS ONLY: FRESH OIL SUPPLY
13 40909 1 HOSE, CORRUGATED, SS, 1/2 NPT X 15”
14 46712 1 CHECK VALVE, 1/2 NPT
15 43850 1 NIPPLE, 1/2, CLOSE, BLACK PIPE
16 46475 1 ADAPTER, QUICK SEAL, 1/2
17 41410 1 PLUG, PIPE, THREADED, 1/2 NPT (Removed when connected to system)
OPTIONAL ON‐BOARD OIL TOP‐OFF ONLY ‐JUG IN BOX (J.I.B.):
18 21358 1 ADAPTER, QUICK SEAL, 1/2
19 42250 1 ELL, 90‐DEG STREET, 1/2 NPT, BLACK PIPE
20 41383 1 FITTING, ELBOW, 3/8NPT MALE TO 1/2 TUBE
21 43850 1 NIPPLE, 1/2, CLOSE, BLACK PIPE
22 40909 1 HOSE, CORRUGATED, SS, 1/2 NPT X 15”
23 96158 1 DRAW TUBE, WELD ASSY, J.I.B, GBF‐70
24 41379 1 COUPLING, MALE, PLASTIC, 1/2 NPT
25 41380 1 COUPLING, FEMALE, PLASTIC, 1/2 TUBE
26 41429 36” HOSE, PVC, 1/2 ID
VAT DRAIN PLUMBING:
27 40820 2 O‐RING, DRAIN VALVE, 1‐1/2”
28 41488 4 SPRING, EXTENSION, 1/2 OD X 2‐1/2”
29 41487 2 COLLAR, SHAFT, 1‐1/2” ID
30 97931 2 PLATE, SPRINGS, DRAIN TUBE
31 97918 1 DRAIN TUBE, SINGLE, GBF‐70
32 41478 1 DRAIN TUBE, FORMED, DOUBLE BANKED, GBF‐70
33 97935 1 DRAIN TUBE BRACKET (ATTACHES TO FRAME)
ITEM PART NO. QTY DESCRIPTION
7.06.1 Plumbing Components - Double Bank Fryer
1
2
3
4
5
6
7
8
BULK
8
W
8
F
9
F
10
F
11
12
13
W
14
15
16
17
18
19
20
21
ON‐B
22
23
24
25
26
27
