GKB 4CH/8CH VFire Server
52
Following is a brief description for each item and its specific operations:
n Mode – the schedule below applies to All cameras or Individual camera.
Press +/- buttons to change the value.
n Camera – select the camera if Individual is selected. Press +/- buttons to
select the camera.
n Start – the start time of this time segment, increment at 30 minutes. (The end
time of this time segment is implicitly set as the start time of next time segment,
or the start time of the first time segment of the same weekday if it’s the last
one.) Press +/- buttons to select the desired start time.
Example: If the user sets the start time of T1/MON as 9:00, T2/MON as 18:00,
T3-T16/MON as N/A (Not Available), then T1/MON is 9:00-18:00,
T2/MON is 0:00-9:00, and 18:00-24:00.
n Alarm – record mode (No, Video, Audio/Video) when certain alarm input is
triggered. “OFF” is for alarm detection OFF. Press +/- buttons to change the
value. Please note that the alarm is the alarm for the focus camera (in Alarm
Setup) if Individual is selected.
n Motion – record mode (No, Video, or Audio/Video) when motion is detected for
certain camera. “OFF” is for motion detection OFF. Press +/- buttons to
change the value.
n Normal – normal record mode, including No, V (Video only), or A/V
(Audio/Video). Press +/- buttons to change the value.
Note: In a time segment, if both Alarm and Motion are set to “OFF”, the
audio/video will be treated as Normal unless there’s Video Loss.
Scheduled Record – Easy Setup
The Scheduled Record – Easy Setup allows the administrator to use a simpler and
easier way to setup the scheduled record of the system. In Easy Setup, there are
Six Selectable Recording Modes: Alarm+Motion+Normal, Alarm+Motion, Alarm,
Motion, Normal, and No Record. Video & Audio are all recorded for the
selectable Recording Modes except “No Record”. After the Easy Setup, the time
segments for each weekday in Scheduled Record will be updated accordingly.
