TX6600PRO INSTRUCTION MANUAL
87
RECEIVER
Sensitivity: -120 dBm for 12 dB SINAD
Intermediate
Frequencies:
1st: 38.85 MHz 2nd: 450 kHz
Adjacent Channel
Selectivity:
> 60 dB (NB)
> 70 dB (WB)
Spurious Response
Immunity:
> 70 dB
Audio Output Power: 1.5 W (8Ω)
Audio Signal to Noise: 34 dB (SINAD)
MECHANICAL AND ENVIRONMENTAL
Dimensions:
59 mm (W) x 42 mm (D) x 128 mm (H)
(not including antenna)
Weight: 337 grams (with battery and antenna)
Operating Temperature: -20° C to +60° C
Ingress Protection: IP67 (dust tight and waterproof)
Accessory Connector: GME 3.5 mm / 2.5 mm stereo jack
NOTE: All values are typical unless otherwise stated and are subject to change
without notice or obligation.
MIL-STD 810G
Standard Method Procedure
High Temperature 501.5 i, ii
Low Temperature 502.5 i, ii
Temperature Shock 503.5 i
Rain Blowing/Drip 506.5 i, iii
Humidity 507.5
Salt Fog 509.5
Dust Blowing 510.5 i
Immersion 512.5 i
Vibration 514.6 i
Shock 516.6 i, iv
