3.4 LAN-connection
The LAN port allows the connection of the Blue Box to a Local Area Network or directly to a PC.
Thus, a retrieval of data and direct communication with the BlueBox is possible. This requires the installation
of the BlueBox PC software on your local computer (see Manual BlueBox PC Software).
The connection to a network is made by a RJ-45-connector at the bottom of the BlueBox (see also 3.2 Con-
nection options).
For this connection you have to choose one of two different connecting cables.
• For connecting to a network you need a standard RJ-45 cable.
• For connecting to a PC you need a RJ-45-crosslink cable.
(Only if the PC has no automatic switch of the network interface.)
Please ensure that the RJ-45-plug snaps into the socket with a “click”!
If the closing cannot be inserted on the socket, please put vaseline on the rubber seal and try it again care-
fully.
Precondition for the protection class IP65:
• tightly twisted connector with protection class IP65 or higher on the
CAN-bus and power connection
∗
• fitted caps on the USB and LAN connection
or
•
USB or LAN connector with protection class IP65 or higher.
∗
The delivered plugs from GO Systemelektronik have the protection class IP65.
