8.2.5.2 Diagram display (actuator)
Actuator menu 8.2.5.1
Displays the status of an actuator over the last 21 to 24 hours (similar 8.2.3.4 Diagram display (sensor val-
ues)).
8.2.5.3 Actuator info
Actuator menu 8.2.5.1
Comment general comment for the actuator
Sensor serial no. i.e. actuator number
Interval Inspection interval for the query function of the actuator
Average 1 - default value for actuators
Resolution 1 - default value for actuators
Parameter switch - default value for relays
Unit not used
Last update The update function is used for a function query and happens after
each inspection interval.
Switches back to the Actuator menu.
Diagram
Diagram
Auto scale Range
Info
Relay 1
Comment Pumpe 1
Sensor serial no. fst002788
Inter val 300
Average 1
Resolution 1
Parameter switch
Unit
Last update 01:33:01 03.04.10
<–
<–
