8.2.1.1.3 Gateway IP-Address (default gateway)
Network menu 8.2.1.1
If the BlueBox shall communicate via the LAN connection with other networks, enter the IP address of the
device that executes the connection (another BlueBox, routers, servers, etc.).
The current value is displayed.
input of the IP address of the gateway with the numeric keys
Network:
IP Address 192.168.1.167
Netmask 255.255.255.0
Gateway
0.0.0.0
Port 14111
Login Name bluebox
Password xxxxx
see 6 The configuration settings sheet, default 0.0.0.0
Deletes the last entered character.
Saves the IP address of the gateway
Switches back to the Network menu.
Gateway
Gateway
0.0.0.0
1 2 3
4 5 6
7
0
8
9
. <
<–
Ok
<
Ok
<–
