BlueBox
GO Systemelektronik GmbH Faluner Weg 1 24109 Kiel Germany Tel.: +49(0)431-58080-0 Fax: -58080-11
Page 74 / 77
www.go-sys.de info@go-sys.de
Appendix D - Example configuration BlueGate-Server
BlueBox settings: see also 8.2.1.1.5.1 UDP settings
Menu Internet settings 8.2.1.1.5
The current value is displayed.
see 6 The configuration data sheet:
BlueGate settings:
IP Address 91.221.182.141
Password BlueGate
xxxxx
Router settings:
For transmission of measurement data to the BlueGate Server the following port must be configured:
• Port 14112 UDP -> 91.221.182.141
For bidirectional communication with the BlueBox the following port must be configured:
• Port 14003 TCP <-> 91.221.182.141
For Windows-Software communication the following port must be configured:
• Port 14002 TCP <-> datagateway.go-sys.de
If a time server is connected to the BlueBox the following configuration is necessary:
• Port 37 TCP/UDP <-> Timeserver IP.
Note: If the internal network is not a Class A, B or C network then communication with the BlueBox is only
possible over: • Port 14110/TCP (SSL encrypted)
Unencrypted communication with the BlueBox is only possible from the following networks:
• 10.0.0.0/8 Class A network
• 172.16.0.0/12 Class B network
• 192.168.0.0/16 Class C network
09:19:39
10.07.10
<–
UDP settings
IP-Address
Encryption on
Password
91.221.182.141
1 2 3
4 5 6
7
0
8 9
.
<
<–Ok
