System ARAMIS Adjustable SRX
Default measuring vol‐
ume [mm]
33 x 25 x 1
to
1370 x 1100 x 1100
Max. frame rate [fps] 335 (full frame), up to 2000 (partial image)
Camera resolution [pix‐
els]
4096 x 3068
Ambient conditions +5 °C to +40 °C (non-condensing)
Voltage range (typical) Supply voltage via GOM Testing Controller
Power consumption Typically 15 W per camera
Connection camera to
PC
10 GigE
Maximum cable length
between sensor and PC
10 m
Tab. 1: Technical data
System Overview
0000001503_002_EN_02-12-2019 Page 11 (56)
