Fig. 21: Calibration panel CP40 in the case (e.g. for MV320)
Fig. 22: Calibration cross CC20, e.g. for MV1400
NOTICE
Inappropriate calibration objects can aect the measuring accuracy.
▶
For calibrating, only use the calibration object which is intended for
the measuring volume!
10.1 How to Handle Calibration Objects
NOTICE
Calibration objects are very sensitive.
Treat the calibration objects with care.
▶
Do not touch the surface of the calibration object!
▶
After each use, duly accommodate the calibration objects!
Info
Clean the surface of the calibration object with the enclosed microfiber
cloth from the standard tool box. Wipe the surface gently only. Never
exert any pressure.
Calibrate the Sensor
0000001503_002_EN_02-12-2019 Page 35 (56)
