Parts
Part No. L40T16 40 kV Electrostatic High Conductivity Air Spray Gun, SeriesB
Part No. L40T15 40 kV High Efficiency Electrostatic Air Spray Gun, Series B
Part No. L60T16 60 kV Electrostatic High Conductivity Air Spray Gun, SeriesB
Part No. L85T16 85 kV Electrostatic High Conductivity Air Spray Gun, SeriesB
Ref.
No.
Part No. Description
Qty
24N665
BODY, gun; 40 kV gun
1
24N666
BODY, gun; 60 kV gun
1
24N667
BODY, gun; 85 kV gun
1
1■
24N668
BODY, gun; 40 kV high
efficiency gun
1
2
See Packing Rod Assembly, page 62
1
3 24N704 NEEDLE, electrode 1
424N623
NOZZLE; includes 4a and 4b
1
4a 24N645
O-RING, conductive
1
4b 111507
O-RING; fluoroelastomer
1
5
24N477
AIR CAP
1
624N644
RING, retainer; includes 6a
1
6a*
198307
PACKING, u-cup; UHMWPE
1
24N659
POWER SUPPLY, 40 kV gun
1
24N660
POWER SUPPLY, 60 kV gun
1
11
24N661
POWER SUPPLY, 85 kV gun
1
11a 24N979
SPRING
1
12 24N663
TRIGGER; includes item 13
1
13 24A445
SCREW, trigger; package of 2
1
14
See High Conductivity Fluid Tube
Assembly, page 67
1
15 24N664
See
Alter
nator Assembly, page 63
1
24N751 HANDLE; 40 kV gun 1
24N752 HANDLE; 60 kV gun 1
16
24N753 HANDLE; 85 kV gun 1
17 185111
SPRING, compression
1
18 197624
SPRING, compression
1
19 249323 VALVE, exhaust 1
19a*
112085
O-RING
1
20 24N741
BRACKET
1
21 24N626
SWIVEL, air inlet; M12 x 1/4
npsm(m); left-hand thread
1
Ref.
No.
Part No. Description
Qty
23 24N633 VALVE, air 1
23a*
276733
SEAL, air valve
1
26 24N630
See ES On-Off and Fluid
Adjustment Valve, page 64
1
27 24N740
SCREW, hex socket; sst;
package of 2
1
28*
24N699
GASKET, ba
rrel
1
29 24T304
See Atomiz
ing Air Restrictor
Valve Asse
mbly, page 65
1
30 24N634
See Fan Air Adjustment Valve
Assembly, page 65
1
34 185116
SPRING, compression
1
35*
188749
PACKING, u-cup
1
36 185103
TUBE, exhaust; 1/4 in. (6 mm)
ID (shipped loose)
1
40 107460
TOOL, wr
ench, ball end; 4 mm
(shippe
dloose)
1
41 276741
MULTI-TOOL (shipped loose)
1
42 24N786
PLUG, restrictor (shipped loose;
for use instead of item 29)
1
43 110231
CLAMP, exhaust tube (shipped
loose)
1
44 116553
GREAS
E, dielectric; 1 oz (30
ml) tu
be (not shown)
1
45 117824
GLOVE, conductive, medium;
package of 12; also available
in small (117823) and large
(117825)
1
24N603
COVER, gun, 40 and 60 kV
guns; package of 10
146
24N604
COV
ER, gun, 85 kV guns;
pac
kage of 10
1
47▲ 179791
TAG, warning (not shown)
1
48▲ 16P802
SIGN, warning (not shown)
1
50 24N783
HOOK; includes screw
1
▲ Replacement Danger and Warning labels, tags,
and cards are available at no cost.
* These parts are included in Air Seal Repair Kit
24N789 (purchase separately).
■ Gun bodies (Ref. 1) include the barrel gasket (Ref.
28).
3A2494E 57
