Graco Pro Xp L40T10 - Hoses

Repair Kits, Related Manuals, and Accessories
Hoses
Grounded Air H
oses
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
0.315 in. (8 mm) ID; 1/4 npsm(f) x 1/4 npsm(f) left-hand thread
Part No. Description
AirFlex Flexible Grounded Air Hose (Gray)
244963
6ft(1.8m)
244964
15 ft (4.6 m)
244965
25 ft (7.6 m)
24N736
25 ft (7.6 m), with 112534 Quick
Disconnect
244966
36 ft (11 m)
24N737
36 ft (11 m), with 112534 Quick
Disconnect
244967
50 ft (15 m)
24N738
50 ft (15 m), with 112534 Quick
Disconnect
244968
75 ft (23 m)
244969
100 ft (30.5 m)
Part No. Description
Standard Grounded Air Hose (Gray)
223068
6ft(1.8m)
223069
15 ft (4.6 m)
223070
25 ft (7.6 m)
223071
36 ft (11 m)
223072
50 ft (15 m)
223073
75 ft (23 m)
223074
100 ft (30.5 m)
0.375 in. (10 mm) ID; 3/8 npsm(f) x 1/4 npsm(f)
left-hand thread
24A225
50 ft (15 m)
24A226
75 ft (23 m)
Part No. Description
Grounded Air Hose with stainless steel braid
ground path (Red)
235068
6ft(1.8m)
235069
15 ft (4.6 m)
235070
25 ft (7.6 m)
235071
36 ft (11 m
)
235072
50 ft (15 m)
235073
75 ft (23 m)
235074
100 ft (
30.5 m)
Fluid H
oses
225 psi (1.4 MPa, 14 bar) Maximum Working
Pressure
1/4 in. (6 mm) ID; 3/8 npsm(fbe); nylon; FM approved.
Part No. Description
2156
37
25 ft (7.6 m)
215638
50 ft
(15 m)
Hig
h Conductivity Fluid Hose
For high conductivity materials. For 60 kV guns only.
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
1/
4 in. (6 mm) ID; 3/8 npsm(f) x 5/8–20(m); ptfe; FM
ap
proved.
Pa
rt No.
De
scription
24N994
26.8 ft (8.2 m)
3A2494E 75
