Graco Pro Xp L40T10 - Air Consumption Charts

Air Caps and Fluid N ozzles
Air Consumpti
on Charts
Key to Air Consumption Charts
TEST CONDITIO
NS: Fan valve fully open; 85 kV
gun.
5/16 in. x 25 ft (8 mm x
7.6 m) hose
5/16 in. x 50
ft (8 mm x
15.2 m) hose
Table 11 . 24N438 Air Cap
AIR CON-
SUMPTION
scfm
WALL PRESSURE
psi
Table 12 . 24N376, 24N276, 24N277, and 24N278
Air Cap
s
AIR C
ON-
SUMP
TION
scfm
WALL PRESSURE
psi
Table13. 24N439AirCap
AIR CON-
SUMPTION
scfm
WALL PRESSURE
psi
Table14. 24N279AirCap
AIR CON-
SUMPTION
scfm
WALL PRESSURE
psi
