Graco Pro Xp L40T10 - Page 59

Parts
Part No. L60M16 60 kV Electrostatic High Conductivity Air Spray Gun, SeriesB
Part No. L85M16 85 kV Electrostatic High Conductivity Air Spray Gun, SeriesB
Ref.
No.
Part No. Description
Qty
24N666
BODY, gun; 60 kV gun
1
1■
24N667
BODY, gun; 85 kV gun
1
2
See Packing Rod Assembly, page 62
1
3 24N704 NEEDLE, electrode 1
424N623
NOZZLE; includes 4a and 4b
1
4a 24N645
O-RING, conductive
1
4b 111507
O-RING; fluoroelastomer
1
5
24N477
AIR CAP
1
624N644
RING, retainer; includes 6a
1
6a*
198307
PACKING, u-cup; UHMWPE
1
24N660
POWER SUPPLY, 60 kV gun
1
11
24N661
POWER SUPPLY, 85 kV gun
1
11a 24N979
SPRING
1
12 24N663
TRIGGER; includes item 13
1
13 24A445
SCREW, trigger; package of 2
1
14
See High Conductivity Fluid Tube
Assembly, page 67
1
15 24N664
See
Alternator Assembly, page 63
1
24N754 HANDLE, smart; 60 kV gun 1
16
24N755 HANDLE, smart; 85 kV gun 1
17 185111
SPRING
, compression
1
18 197624
SPRING
, compression
1
19 249323 VALVE, exhaust 1
19a*
112085
O-RIN
G
1
20 24N741
BRACK
ET
1
21 24A626
SWIVE
L, air inlet; M12 x 1/4
npsm(
m); left-hand thread
1
23 24N633 VALVE, air 1
23a*
276733
SEAL, air valve
1
Ref.
No.
Part No. Description
Qty
24 245265
CIRCUIT, flexible
1
26 24N630
See ES On-Off and Fluid
Adjustment Valve, page 64
1
27 24N740
SCREW, hex socket; sst;
package of 2
1
28*
24N699
GASKET, bar
rel
1
29 24T304
See Atomizi
ng Air Restrictor
Valve Assem
bly, page 65
1
30 24N634
See Fan Air Adjustment Valve
Assembly, page 65
1
31 24N756
See Smart Module Assembly,
page 66
1
34 185116
SPRING, c
ompression
1
35*
188749
PACKING,
u-cup
1
36 185103
TUBE, exh
aust; 1/4 in. (6 mm)
ID (ship
ped loose)
1
40 107460
TOOL, wrench, ball end; 4 mm
(shipped loose)
1
41 276741
MULTI-TOOL (shipped loose)
1
42 24N786
PLUG, restrictor (shipped loose;
for use instead of item 29)
1
43 110231
CLAMP,
exhaust tube
1
44 116553
GREASE
, dielectric; 1 oz (30 ml)
tube (
not shown)
1
45 117824
GLOVE, conductive, medium;
package of 12; also available
in small (117823) and large
(117825)
1
24N603
COVER, gun, 60 kV guns;
package of 10
1
46
24N604
COVE
R, gun, 85 kV guns;
pack
age of 10
1
47▲ 179791
TAG, warning (not shown)
1
48▲ 16P802
SIGN, warning (not shown)
1
50 24N783
HOOK; includes screw
1
▲ Replacement Danger and Warning labels, tags,
and cards are available at no cost.
* These parts are included in Air Seal Repair Kit
24N789 (purchase separately).
■ Gun bodies (Ref. 1) include the barrel gasket (Ref.
28).
3A2494E 59
