Parts
Part No. L60M10 60 kV Electrostatic Air Spray Gun, Series B
Part No. L60M12 60 kV Electrostatic Air Spray Gun, Series B, with 1.2 mm Nozzle
Part No. L85M10 85 kV Electrostatic Air Spray Gun, Series B
Ref.
No.
Part No. Description
Qty
24N666
BODY, gun; 60 kV gun
1
1■
24N667
BODY, gun; 85 kV gun
1
2
See Packing Rod Assembly, page 62
1
3 24N651 NEEDLE, electrode 1
24N616
NOZZLE, 1.5 mm; includes 4a
and 4b
1
4
24N615
NOZZLE, 1.2 mm; includes 4a
and 4b
1
4a 24N645
O-RING, co
nductive
1
4b 111507
O-RING; flu
oroelastomer
1
5
24N477
AIR CAP
1
624N644
RING, ret
ainer; includes 6a
1
6a*
198307
PACKING,
u-cup; UHMWPE
1
7‡
111286
FERRULE,
front
2
8‡ 111285 FERRULE, back 2
24N657
FITTING
, fluid; 60 kV gun
1
9
24N658
FITTING
, fluid; 85 kV gun
1
10 102982
PACKING
, o-ring
1
24N660
POWER S
UPPLY, 60 kV gun
1
11
24N661
POWER S
UPPLY, 85 kV gun
1
11a 24N979
SPRING
1
12 24N663
TRIGGE
R; includes item 13
1
13 24A445
SCREW
, trigger; package of 2
1
24N696
TUBE,
fluid, with sleeve; 60 kV
gun
1
14
24N697
TUBE, fluid, with sleeve; 85 kV
gun
1
15 24N664
See
Alternator Assembly, page 63
1
24N754 HANDLE, smart; 60 kV gun 1
16
24N755 HANDLE, smart; 85 kV gun 1
17 185111
SPR
ING, compression
1
18 197624
SPR
ING, compression
1
19 249323 VALVE, exhaust 1
19a
*
112085
O-R
ING
1
20 24N741
BR
ACKET
1
Ref.
No.
Part No. Description
Qty
21 24N626
SWIVEL, air inlet; M12 x 1/4
npsm(m); left-hand thread
1
22 24N698 NUT 1
23 24N633 VALVE, air 1
23a*
276733
SEAL, air valve
1
24 245265
CIRCUIT, flexible
1
26 24N630
See ES On-Off and Fluid
Adjustment Valve, page 64
1
27 24N740
SCREW, hex
socket; sst;
package of
2
1
28*
24N699
GASKET, barrel
1
29 24T304
See Atomizing Air Restrictor
ValveAssembly,page65
1
30 24N634
See Fan Air Adjustment Valve
Assembly, page 65
1
31 24N756
See Smar
t Module Assembly,
page 66
1
34 185116
SPRING, compression
1
35*
188749
PACKING, u-cup
1
36 185103
TUBE, exhaust; 1/4 in. (6 mm)
ID (shipped loose)
1
40 107460
TOOL, wrench, ball end; 4 mm
(shipped loose)
1
41 276741
MULTI-TOOL (shipped loose)
1
42 24N786
PLUG, restrictor (shipped loose;
for use instead of item 29)
1
43 1102
31
CLAMP, exhaust tube (shipped
loose)
1
44 116553
GREASE, dielectric; 1 oz (30
ml) tube (not shown)
1
45 117824
GLOVE, conductive, medium;
package of 12; also available
in small (117823) and large
(117825)
1
24N
603
COVER, gun, 60 kV guns;
package of 10
146
24N604
COVER, gun, 85 kV guns;
package of 10
1
47▲ 179791
TAG, warning (not shown)
1
48▲ 16P802
SIGN, warning (not shown)
1
50 24N783
HOOK; includes screw
1
▲ Replacement Danger and Warning labels, tags,
and cards are available at no cost.
*
These parts are included in Air Seal Repair Kit
24N789 (purchase separately).
‡ These parts are included in Fluid Seal Repair Kit
24N790 (purchase separately).
■
Gun bodies (Ref. 1) include the barrel gasket (Ref.
28).
3A2494E 61
