FHO5000
27
5.0 Expanding the Waveform and
Moving the Display Area
In "current test" interface, pressF4button to switch between "Curve"and
"Event", expend each section after switch, this function could also switch
between cursor("Curve") and selection tag("Event").
Procedure:
In test interface,
1. PressF4button to switch from curve to event windows.
2. Control】/【 or 】/【to move selection tag.
5.1 Switching between Event List and Display Window
Original event window
Event window became larger
Switch to "Event", move selection tag to choose event.
