400X
1.0
0.40*0.31
-18~35
235*95*30
1/3 inch 2 million of pixel
0.15
1.1/2.0
FHO5000
44
12.0 FIM Module(Optional)
FIM Module Interface
Capture Image
Save current image
Bright/Contrast
Adjust Bright and Contrast for image
Reset
Recover to factory settings
Specification
Magnification
Resolution(μm)
View of Field(mm)
Storage/working Condition
Dimension(mm)
Sensor
Weight(Kg)
USB
FIM Module is qualified for field connector inspection by connecting a probe to USB port, also this probe can
use computer as a display with no additional software.
