FHO5000
32
This function could used to switch between several curves ,current curve
displayed in yellow.
Procedure :
In "Current Test" interface,
1. PressF2button , active "switch"function.
2. Control】/【 button to switch between curves.
:Switch to above curve :switch to below curve
3. PressOKbutton to reset all curves
5.5 Switching between Curves
A Curve
B Curve
C Curve
After on operation,
curve A switch to curve B
After another operation
curve B switch to curve C
Caution

Display maximum 8 curves at one time, if load more than 8 curves last
curve will recover the former one, please refer 6.2 "Loading Curve(S)" for
learning how to load curve(s).
User could remove one or several curves.
Press F3 "Overlay"tag menu:
Remove Current Trace Remove the Curve which has been selected.
Remove Other Trace Remove the Curve(s) which has not been selected.
Remove All Remove all the Curves.
5.5.1 Removing Curve(s)
