FHO5000
50
17.2 Cleaning Tools
Optic fiber cleaner (for cleaning of optic connectors)
Optic fiber cleaning rod (for cleaning of optic outputs)
Optic fiber cleaning tissue (for cleaning optic interfaces)
Isopropyl alcohol
Cotton ball
Paper tissue
Cleaning brush
Compressed
17.3 Cleaning of Optical Port
Procedure:
1. Screw down the cap.
2. Pull out ceramic core by fingers.
3. Clean port carefully.
4. Recover ceramic core.
5. Screw on the cap.
Structure of optical port
17.4 Calibration
We suggest to calibrate FHO5000 OTDR twice a year, for more
information please contact us(check section 17.4 "Customer Service
and Support" to find our contact information ).
Caution
Be careful, don't use tools like plier,
it may cause permanent damage to
optical port
