FHO5000
55
Magnification
Resolution
View of Field
Storage/working Condition
Dimension
Sensor
Weight
USB
Adapter
400X
1.0µm
0.40×0.31mm
-18~35
235×95×30mm
1/3 inch 2 million of pixel
150g
1.1/2.0
SC-PC-F(For SC/PC connector)
FC-PC-F(For FC/PC connector)
LC-PC-F(For LC/PC connector)
2.5mm -Male (For 2.5mm adapter)
online(use 1625nm wavelength) and will not interrupt the fiber signal.
Dynamic range is measured with maximum pulse width,averaging time is 3 minutes
Event dead zone is measured with minimum pulse width
1310/1490/1550nm laser source use OTDR1 port, 1625nm uses OTDR2port, 1625/1650nm or 850/1300nm
uses OTDR3 port..
For more adapters please contact us
Model T40F/T43F/T45F/TC35F are intergrated with optical filter, this allow them to test PON network
Working wavelength
Output power
Accuracy
Connector
850/1300/1310/ 1550/1625/1650nm
-25~0dBm
±0.5dB
FC/UPC
1490/
OLS Module(Optional)
FIM Module(Optional)
