Grandway Optical Instruments Series User Manual

FHO5000
54
Wavelength
Power
Range
Connector
Launching Mode
650nm
10mw,CLASSIII B
12km
FC/UPC
CW/2Hz
Sensor Type
Wavelength Range
Calibrated Wavelength
Testing Range
Resolution
Accuracy
Adapter
InGaAs
800~1700nm
850/1300/1310/1490/1550/1625/1650nm
-50~+10dBm
0.01dB
±0.35dB±1nW
FC/UPC
Pulse width
Testing distance
Sampling resolution
Sampling point
Linearity
scale indication
Loss threshold
Loss resolution
Distance resolution
Distance accuracy
Refractivity Setting
3ns, 5ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs, 5μs, 10μs, 20μs
Dead zone test(100m), 500m, 2km, 5km, 10km, 20km, 40km, 80km, 120km, 160km,240km
Minimum 0.25m
Maximum 128,000 points
≤0.05dB/dB
X axis: 4m~70m/div, Y axis:0.09dB/div
0.01dB
0.001dB
0.01m
-5
±(1m+measuring distance×3×10 +sampling resolution)
1.4000~1.7000, 0.0001 step
VFL Module
Test parameter
OPM Module(Optional)
