FHO5000
45
13.0 Waterproofing work(Optional)
Through special process, FHO5000 can compliance with IPX5 protection level. This could make FHO5000 withstand
harsher environments.Test for the ratings IPX5 address the possibility of water ingress from a jetting stream.They are
conducted using a jet nozzle kit .
14.0 Touch Screen (Optional)
After slelect this optional module ,a Resistance Screen will be added to FHO5000,user could select item or input words
by just touch the relvent area,a specialized pen is attached.
Calibration
Once you cann’t touch the certain point you want on screen that means you
need to calibrate the touch screen.
Please follow next procedure to proceed calibration:
Warning
Press gently on the screen, any strike or
crash may damage it.
!
1. Open"system setting"interface and select "Touch
Screen Calibration"area,enter calibration interface.
2. Follow the direction, press"+"icons on the screen,then
calibration done.
Start calibration from here
To Next Page
