850/1300/1310/1490/1550/1625/1650nm①
-25~0dBm
±0.5dB
FHO5000
43
11.0 OLS Module(Optional)
OLS Module interface
Start
Turn on the laser source
WL switch
Switch between wavelengths
Power Increase
Increase the power value
Power Decrease
Decrease the power value
Shutdown
Turn off the laser source
Specification
Working wavelength
Output power
Accuracy
①
OTDR2port, OTDR can not use 1620nm or 850/1550nm without OTDR2 module
1310/1490/1550nm wavelength use OTDR1 port, while 1625/1650nm or 850/1550nm wavelength use
