7 DISASSEMBLY AND REASSEMBLY
7.3 Belt Tension Adjustments
7.3.1 Y-Belt Tension Adjustment
How to adjust the Y-belt tension
(1) Tighten the two adjustment screws to the marking position, which was marked when detaching the Y
belt.
Adjustment screw
(M3L28 binding head screw)
Marking position
Y idler pulley
