Model G1026 (Mfd. Since 10/13)
-3-
A. Work Table
B. Hold Down
C. Fence (1 of 2)
D. Cutterhead Guard
E. Spindle Assembly
F. Miter Gauge
G. Guard Lock Handle
H. Fence Adjustment Knobs
I. Guard Lock Knob
J. Fence Lock Handle (1 of 2)
K. Spindle Height Scale
L. Magnetic Switch
M. Motor Cover
N. Forward/Reverse (FOR/REV) Switch
O. Spindle Elevation Handwheel
P.
Safety Guard
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
A
B
C
D
E
L
M
N
I
O
G
For Your Own Safety Read Instruction Manual Before Operating Shaper
a) Wear eye protection.
b) Always keep cutterhead guard in place and in proper operating condition.
c) Be sure keyed washer is directly under spindle nut and spindle nut is tight
d) Feed workpiece AGAINST rotation of cutter.
e) Keep fingers away from revolving cutter–use fixtures when necessary.
f
) Do not use awkward hand positions.
P
F
K
J I
H
