Model G1026 (Mfd. Since 10/13)

-5-

Machine Data Sheet

The information contained herein is deemed accurate as of 4/24/2017 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.

PAGE 1 OF 2

Model G1026

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G1026 3 HP SHAPER

Product Dimensions:

Weight.............................................................................................................................................................. 345 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 30 x 30-1/2 x 39-1/2 in.

Footprint (Length x Width)............................................................................................................................ 20 x 21 in.

Shipping Dimensions:

Type..................................................................................................................................................... Cardboard Box

Content........................................................................................................................................................... Machine

Weight.............................................................................................................................................................. 392 lbs.

Length x Width x Height....................................................................................................................... 31 x 26 x 42 in.

Must Ship Upright................................................................................................................................................... Yes

Electrical:

Power Requirement........................................................................................................... 240V, Single-Phase, 60 Hz

Prewired Voltage.................................................................................................................................................. 240V

Full-Load Current Rating........................................................................................................................................ 12A

Minimum Circuit Size.............................................................................................................................................. 15A

Connection Type....................................................................................................................................... Cord & Plug

Power Cord Included.............................................................................................................................................. Yes

Power Cord Length................................................................................................................................................. 6 ft.

Power Cord Gauge......................................................................................................................................... 14 AWG

Plug Included.......................................................................................................................................................... Yes

Included Plug Type................................................................................................................................................ 6-15

Switch Type.................................................................................................... Magnetic Switch w/Overload Protection

Motors:

Main

Type................................................................................................................. TEFC Capacitor-Start Induction

Horsepower................................................................................................................................................ 3 HP

Phase............................................................................................................................................ Single-Phase

Amps............................................................................................................................................................ 12A

Speed................................................................................................................................................ 3450 RPM

Power Transfer .................................................................................................................................. Belt Drive

Bearings..................................................................................................... Shielded & Permanently Lubricated

Main Specifications:

Operation Info

Max. Cutter Height................................................................................................................................. 2-1/2 in.

Max. Cutter Diameter............................................................................................................................ 5-1/2 in.

Spindle Sizes................................................................................................................................. 1/2, 3/4, 1 in.

Spindle Lengths....................................................................................................................... 2-3/4, 3-1/2, 3 in.

Exposed Spindle Length........................................................................................................................ 3-1/8 in.

Spindle Cap. Under the Nut.................................................................................................... 2, 2-1/2, 2-1/4 in.

Spindle Speeds................................................................................................................... 7,000, 10,000 RPM

Spindle Travel.............................................................................................................................................. 3 in.

Spindle Openings...................................................................................................................... 1-1/2, 3, 4, 7 in.
